| Article Name | 50μm Pane silver PVC/water base/140gsm Single coated liner | Code | WL5050 | ||
| Face Stock | Liner | ||||
| Article Name | Indigo digital coated PVC | Article Name | Single copper bottom | ||
| （μ） Thickness | 50±3 | （μ） Thickness | 135±3 | ||
| （g/m） Basic Weight | 70±3 | （g/m） Basic Weight | 135±3 | ||
| Color | Pane silver | Color | white | ||
| Surface tension | ~~ | （g/in） Release Force | 10-15g | ||
| Adhesive | |||||
| Water-based adhesive | |||||
| Properties | Value | Unit | Test Method | ||
| Thickness | 16±3 | μ | ISO534 | ||
| Dry Coating Weight | 18±3 | g/m2 | FTM12,SS | ||
| 180° Peel Force | ≥6 | N/25mm | FTM1 , SS | ||
| Annular initial tack | ≥8 | N/25mm | FTM9,SS | ||
| Sustained tack | ≥24 | H/25mm | FTM8,SS | ||
| Service Temperature | -20-70 | ℃ | ~~ | ||
| Min-Labeling Temperature | 5 | ℃ | ~~ | ||
| Storage Condition | Storage conditions are normal temperature, a cool, ventilated and dry place (0~28℃, below 70%RH), avoid high temperature and humidity, and do not expose to the sun or rain. The best storage conditions are 23±5℃, 65±5%RH, and the shelf life is for 12 months. Note: If the product is placed under conditions where the temperature and humidity are too high or too low for a long time, the shelf life will be significantly shortened. | ||||
| Statement | The above technical data are average data obtained through multiple inspections using recognized and reliable inspection methods, but do not constitute a guarantee. In order to ensure the correct use of our products, please be sure to test them on the corresponding substrate and use environment to verify the use effect before using our products. To confirm whether it meets the requirements of the base material and usage environment, determine which material to purchase. At the same time, our company reserves the right to improve technical specifications without prior notice. Since the usage is beyond our control, our company is not responsible for any losses caused by use. ·Our company is responsible for retaining the right of final interpretation. | ||||
